These High Flow Series filters feature a larger geometry to handle higher flows with fewer filter elements. The result is much faster, easier filter changeouts. In addition, the inside to outside flow allows for excellent dirt holding capacity, extending the time between filter changeouts.
Features
- 6" diameter, large geometry for high flow rates
- Absolute retention ratings from 1 to 100 microns
- Capable of flow rates up to 500 GPM in a single 60" element
- Inside-out flow retains contaminant even during changeout
- Multi-layer pleated construction with optimized surface area
- Outer cage prevents media extrusion problem experienced with some competitive offerings
- Unique Quad Seal gasket provides maximum seal integrity
Specifications
- Material: Polypropylene
- Micron Ratings: 1, 3, 5, 10, 20, 40, 60, 75, 100
- Lengths: 20", 40", 60"
- Outside Diameter: 6.0"
- Gaskets/O-rings: Buna-N, EPDM, Silicone, Viton, Teflon encapsulated Viton
Used by real customers in the following industries: Industrial Manufacturing, A&E/Environmental Services, Municipal Water, Oil & Gas, Food & Beverage, Chemicals, Polymers, Inks, Paint & Coatings, Microelectronics, General Contractor, Schools & Hospitals
